Highlights

  • High-efficiency M10 Mono PERC bifacial solar cells with power output up to 560W
  • Up to 15% additional rear-side power gain depending on ground reflectivity
  • Anti-staining transparent backsheet reduces rear-side cleaning and water usage
  • Cylindrical tabbing wire minimizes shadowing and improves light absorption
  • Split junction box with bypass diodes enhances performance under partial shading
  • Multi-busbar design increases micro-crack tolerance and reduces efficiency loss
  • Lightweight design allows easy installation, including east-west orientation
  • Lower internal resistance improves power output and reduces energy loss
  • Certified to IS 14286:2010 / IEC 61215 & IEC 61730 standards
  • BIS Registration Nos: R-51000566, R-61002070
Brand: Vikram Solar

Vikram 535–560W High-Efficiency Bifacial PV Modules with Glass-to-Transparent Backsheet

SKU: SP00034

Freedom Sale

Hurry and get discounts on all solar products up to 10%

FREEDOM10

Highlights

  • High-efficiency M10 Mono PERC bifacial solar cells with power output up to 560W
  • Up to 15% additional rear-side power gain depending on ground reflectivity
  • Anti-staining transparent backsheet reduces rear-side cleaning and water usage
  • Cylindrical tabbing wire minimizes shadowing and improves light absorption
  • Split junction box with bypass diodes enhances performance under partial shading
  • Multi-busbar design increases micro-crack tolerance and reduces efficiency loss
  • Lightweight design allows easy installation, including east-west orientation
  • Lower internal resistance improves power output and reduces energy loss
  • Certified to IS 14286:2010 / IEC 61215 & IEC 61730 standards
  • BIS Registration Nos: R-51000566, R-61002070
Brand: Vikram Solar

Get a Quote

    10 People watching this product now!

    Payment Methods:

    Payment methods

    Description

    Vikram’s 535–560W bifacial PV modules with glass-to-transparent backsheet technology represent a breakthrough in solar innovation, offering exceptional performance, efficiency, and design. These modules are engineered to capture sunlight from both the front and rear sides, allowing for higher energy yields, especially when installed over reflective surfaces such as white rooftops, sand, or concrete. This bifacial advantage ensures superior performance across diverse installation environments.

    The transparent backsheet design not only reduces the overall weight compared to traditional glass-glass bifacial modules but also enhances thermal management and mechanical strength. This makes the modules easier to handle and install, especially in large-scale solar projects. The use of high-quality materials ensures long-term durability and resistance to environmental factors such as UV exposure, moisture, and mechanical stress.

    With a power output range of 535–560W and a high conversion efficiency, these modules are well-suited for utility-scale, commercial, and industrial solar power systems. They are built using advanced multi-busbar and half-cut cell technologies, which help in reducing power loss, improving shade tolerance, and enhancing overall performance even under partial shading conditions.

    Backed by Vikram’s strong legacy of manufacturing excellence and stringent quality standards, these modules deliver not just reliable power generation but also peace of mind. With robust warranties and proven field performance, Vikram’s bifacial PV modules offer an ideal solution for anyone looking to maximize their solar investment with next-generation technology.

    Specification

    Electrical Specifications

    Bifaciality Factor (%)

    70% – 85%

    Maximum Power Current (Imp)

    12.87 ~ 13.32 A

    Maximum Power Voltage (Vmp)

    41.6 ~ 42.1 V

    Maximum System Voltage (V)

    1500 V DC

    Open Circuit Voltage (Voc)

    49.4 ~49.9 V

    Rear Side Gain (%)

    ~

    Short Circuit Current (Isc)

    13.56 ~ 14.05 A

    Temperature Coefficient

    -0.35 % / °C

    Mechanical Details

    Weight 28.2 kg
    Dimensions 2274 × 1134 × 35 cm
    Cables & Connectors

    MC4 Compatible

    Frame Material

    Anodized aluminum

    Glass Type

    High Tramission ARC

    ,

    Tempered Glass

    Junction Box Rating

    IP68

    Mechanical Load Capacity

    5400 Pa (front) / 2400 Pa (rear)

    General

    Cell Type

    Efficiency (%)

    No. of Cells

    144

    Power Rating (Wattage)

    ,

    ,

    ,

    ,

    ,

    Panel Type

    Warranty (Years)
